ASUS B80A Business Notebook Technical Specifications


ASUS B80A Business Notebook Technical Specifications

ASUS B80A Business Notebook Stylish, powerful and versatile with robust integrated security, the ASUS B80A notebook powered by Intel Centrino 2 Processor Technology is ideal for corporate users who demand the most from their notebooks.

As the new flagship system for the ASUS line of business notebooks, the B80A with a 14.1-inch widescreen is packed with the powerful features, robust security and stylish build that corporate users look for in their notebooks of choice. The B80A features an integrated fingerprint reader and TPM-level security that protect files and data from unauthorized access, without compromising convenience and user-friendliness. Equipped with an Intel® Wi-Fi Link 5100 wireless adapter, the B80A ensures wireless Internet access whenever reception is available. The B80A also supports Bluetooth 2.1 EDR. ASUS SmartLogon—Quick Sign-ins through Face Recognition, This exclusive face recognition software offers an easy way to sign into windows without having to key in any passwords.

ASUS B80A Business Notebook Detailed Technical Specifications:

Operating SystemGenuine Windows Vista® Ultimate,
Genuine Windows Vista® Business,
Genuine Windows Vista® Home Premium,
Genuine Windows Vista® Home Basic,

Processor & Cache MemoryIntel® Core™2 Duo Processor T9400/P8600/P8400/P7350/T5900/T5800/T5750 : 2.53 GHz - 2 GHz, FSB 1066/800/667MHz, 6/3/2 MB L2 Cache;

Intel® Core™2 Duo Processor T1700/T1600 : 1.83 GHz - 1.66 GHz, 667 MHz, 1MB L2 Cache
Chipset_testMobile Intel® GM45 Express Chipset +ICH9M
Main MemoryDDR2 800 MHz SDRAM, 2 x SODIMM socket for expansion up to 4GB SDRAM
*Due to the 32-bit operation system's limitation, only 3GB will show up with a 4GB memory. The 64-bit operating system will not have this issue. For more information, please check Microsoft's support site: http://support.microsoft.com/kb/946003
Display14.1" WXGA/WXGA+ Color-Shine (Glare-type),Asus Splendid Video Intelligent Technology

Video Graphics & MemoryEmbedded Intel® GMA X4500HD Gfx
Hard Drive2.5" 9.5mm SATA

320GB,5400rpm
250GB,5400rpm;7200rpm
Optical Drive5.25" , 9.5 mm
DVD Super Multi Double Layer:

Card Reader8 in 1 card reader, SD,MMC,MS,MS-Pro,mini SD w/ adapter,MS-Duo,MS-Pro Duo via adapter
Video Camera1.3 Mega Pixel web camera

Fax/Modem/LAN/WLANIntegrated Intel® High Definition Audio chip (Azalia) and 10/100/1000 BaseT
Built-in Bluetooth™ V2.1+EDR (optional)
Intel® Wireless WiFi Link 5100 ABGN

LED Status IndicatorPower-on/Suspend
Battery Charging/full/low
Storage device access
Capital / Scroll / Number Lock
Wireless on status indicator
Bluetooth on status indicator
Email in box

Interface1 x Express card
1 x Microphone-in jack
1 x Headphone-out jack (S/PDIF)
1 x VGA port/Mini D-sub 15-pin for external monitor
3 x USB 2.0 ports
1 x IEEE 1394 port
1 x RJ11 Modem jack for phone line
1 x RJ45 LAN Jack for LAN insert
1 x HDMI
1 x Docking Connector (hot swappable)
Hot KeysInstant launch Keys,5 buttons:
Power On/Off,Touchpad Lock,Power4 Gear+,Keybard Lighting LED,Express Gate

Function Keys:
Fn+F1 Suspend switch
Fn+F2 WLAN switch
Fn+F2 Bluetooth switch
Fn+F3 Access to the E-mail
Fn+F4 Access to the Internet
Fn+F5 Brightness down
Fn+F6 Brightness up
Fn+F7 LCD on/off
Fn+F8 LCD/CRT switch display
Fn+F9 TouchPad Lock
Fn+F10 Volume on/mute
Fn+F11 Volume down
Fn+F12 Volume up
Fn+Ins Numeric Key Pad on/off
Fn+Space Power 4Gear +
Fn+C Splendid
Fn+T Power4Phone
Fn+V Camera capture
Fn+↑: Stop
Fn+↓: Play/Pause
Fn+ ←: Skip to Previous Track
Fn+ →: Skip to Next Track
AudioBuilt-in Azalia compliant audio chip, with 3D effect & full duplex
Built-in stereo speakers

KeyboardStandard Keyboard with 88 keys

Battery Pack & Life6 cells: 4800 mAh,
9 cells: 7800 mAh,

AC AdapterOutput: 16 V DC, 4.7 A, 65w
Input: 100-240 V AC, 50/60 Hz universal

Dimension & Weight34.1 x 24.5 x 2.98~3.70 cm (W x D x H)
2.46 kg (with 6cell battery)

SecurityBIOS Booting / HDD User Password Protection and security lock
Kensington lock hole
Fingerprint(optional)
Supplied AccessoriesOptical Mouse
Carrying bag

Multimedia SoftwareASUSDVD V7.0 ( *For Basic & Business only)
Power Director V5.0 (*For Basic & Business only)
Medi@Show V3.0 (*For Basic & Business only)

Virus & Tool SoftwareNorton™ Internet Security 2008
Adobe Acrobat Reader 8.0
NERO 8 Essentials
Power2Go
ASUS UtilityAsus Win flash for BIOS and Driver live Update
ASUS CopyProtect
ASUS SmartLogon
ASUS Net 4 switch
Asus Power4Gear eXtreme
Asus Live Update
Asus Multi-Frame
Power 4 Phone
Asus NB Probe +
ASUS Life Frame 3
ASUS Wireless Console
ASUS Security Protect Manager(ASPM)
Virtual Camera
ASUS Splendid
ASUS Express Gate
Infineon Security Platform Host SW (W/TPM Model)
Warranty & e-support2-year limited global hardware warranty
*different by country
1-year battery pack warranty
On-line problem resolution through web interface (BIOS, Driver update)
OS (Windows Vista) install/uninstall consultation
Bundled software install/uninstall consultation
ASUS software supporting

OS CompatibilityWindows Vista/Windows XP





Intel, the Intel logo, Centrino and the Centrino logo, Intel Core and Core Inside, are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United States and other countries.

  • All specifications are subject to change without notice. Please check with your supplier for exact offers. Products may not be available in all markets.
  • PCB color and bundled software versions are subject to change without notice.
  • Brand and product names mentioned are trademarks of their respective companies.
