Sony PCG-C1VSX/K,C1VS/BW Main Specification

Sony PCG-C1VSX/K,C1VS/BW Main Specification

Sony PCG-C1VSX/K,C1VS/BW  Sony PCG-C1VSX/K,C1VS/BW (Japan model) Main Specification Original from here.


Windows 2000 ProfessionalWindows Millennium Edition


Transmeta Crusoe processor
TM5600, 667 MHzTM5600, 600 MHz

Cache-memory (Primary/second)

128KB/512KB (built-in to CPU)

Processor system bus

100MHz (at the time of CPU clock 600MHz operation)

Main memory standard/maximum

SDRAM 128MB (onboard)/maximum 192MB * you use inside 16MB with the system.

Expansion storage slot (Being less crowded)

Private memory slot ×1(1)

Graphic accelerator

ATI RAGE Mobility-M1 (3D correspondence)

Video memory

8MB (built-in to video tip/chip)

Liquid Crystal Display

8.9 Type and ultra wide XGA (1024×480 dot) corresponding TFT color liquid crystal

Indicatory mode

1024×480 (largest approximately 16,770,000 color *1) /640×480 (largest approximately 16,770,000 color *1), 800×600*2 (largest approximately 16,770,000 color *1), 1024×768*2 (largest approximately 16,770,000 color *1)

External display output

1600×1200/1280×1024/1024×768/800×600 (approximately 16,770,000 color)

Dual display indicatory time (Example)

(Non correspondence)External display: 1280×1024 (Largest approximately 16,770,000 color) - Substance LCD indication: 1024×480 (Largest approximately 16,770,000 color *1) External display: 1024×768 (Largest approximately 16,770,000 color) - Substance LCD indication: 1024×480 (Largest approximately 16,770,000 color *1)

Floppy disk drive

External by way of selling separately PCGA-UFD5 and USB, 3.5 types (1.44MB/720KB)

Hard disk

Approximately 30GB (Ultra ATA) (C: Approximately 15GB/D: Approximately 15GB) *3*4Approximately 15GB (Ultra ATA) (C: Approximately 10GB/D: Approximately 5GB) *3


Selling separately: CD-ROM drive (PCGA-CD51/A) CD-RW drive (PCGA-CDRW52) DVD-ROM drive (PCGA-DVD51/A) PC card connectionAttachment: CD-RW drive (PCGA-CDRW52) PC card connection

Built-in video camera

Progressive system 1/6 type CCD 350,000 pixel (f=2.8mm F2.8)

External connected terminal

?AV output (NTSC/PAL correspondence and stereo line output) *5 ?USB×1 - External display output (optional display adapter PCGA-DA1S private terminal) ×1 ?i.LINK (IEEE1394) terminal S400 (4 pins) the modular jack ×1 for ×1 ? modem - Microphone/line input (monaural/stereo combined use mini- jack) ×1 - Stereo headphone output (MEGA BASS correspondence) ×1 - Magic gate corresponding memory stick slot ×1

PC card slot

Type II×1 and CardBus correspondence

Wireless communication facility

In substance Bluetooth built-in *6 (Maximum transmission speed 723kbps, Distance you foresee, approximately 100~10m) the *7 (Bluetooth1.0B conformity)-

Audio function

Windows sound system interchangeability and built-in stereo speaker, Built-in microphone, XG corresponding hardware MIDI sound source, MEGA BASS (silent boost) function (only headphone output)

Built-in FAX/modem

Maximum 56kbps*8 (V.90/K56flex automatic correspondence)/maximum 14.4kbps (at the time of FAX)

Keyboard/ Pointing device

Approximately 17mm pitch/key stroke approximately 2mm/86 key/ Scroll functional corresponding stick type pointing device *9, [jiyogudaiyaru]

Main accessory

AC adapter (PCGA-AC16V2 equal item), Battery pack (S) (PCGA-BP51A equal item) *10, Telephone cord/code (modular cable), AV connector cable (Pin plug: Image/stereo ?AV mini- plug: Special stereo mini- plug), Recovery CD
-Microsoft Office XP Personal Preinstallation package

Power source

AC adapter or lithium ion battery

Electric power consumption


It is based on out energy law Energy consumption efficiency *11

S division 0.0010

Battery drive time *12

Battery pack (S): Approximately 2.5~5.5 time/ Battery pack (L): Approximately 5.5~10.5 time/ Battery pack (LLL): Approximately 9~18.5 timeBattery pack (S): Approximately 3~5.5 time/ Battery pack (L): Approximately 6~11 time/ Battery pack (LLL): Approximately 10~19 time

Battery charge time (Also when turning on/off)

Battery pack (S): Approximately 1.5 hours (approximately 85%), approximately 2.5 hours (approximately 100%)/ Battery pack (L): Approximately 3.5 hours (approximately 85%), approximately 6 hours (approximately 100%)/ Battery pack (LLL): Approximately 6 hours (approximately 85%), approximately 9 hours (approximately 100%)

Warm humidity condition

When operating 5~35? (temperature gradient 10?/time below) 20%~80% (However as for the humidity in thing, and the 35? which do not become wet with dew 65% or less)

Substance external size (Largest spine not being included)

Approximately width 248mm× height 27mm (forward the most it is thin section. Rear section 29mm) ## depth 152mm


Approximately 995g (battery pack (S) when loading)Approximately 980g (battery pack (S) when loading)
*1 With the dither ring function of the graphic accelerator actualization.
